- Model: Digital Multimeter
Digital Multimeter
Size: 18.6*8.6*4.1 cm
Display: Lcd screen, hight for letter: 25mm
Feature: With thick silicon shell for protection
Max display value: 19999 or 1999
Working temperature range: 0-40 ℃ (32 - 104 ℉)
Storage temperature range: -10 - 50 ℃ (14 - 122 ℉)
Reading display rate: 2-3 times/S
Over range indicator: The highest level display 1
Automatic negative polarity display: "-"
Data hold state: "D.H"
Full range protection function
Capacitance measurement automatic zero
Auto power off: the instrument can automatically cut off the power of the instrument on about 15 minutes, repeat the power switch can be switched on.
Power source: 1 pc 9V battery IEC 6F22 NEDA 1604 JIS006P
Weight: about 270 g (incl. battery)
Technical index as below:
No. | Item | Range | Resolution | Accuracy |
1 | DC voltage | 200mV - 1000V | 100uV - 1V | ±(0.5%+5d) - ±(0.8%+5d) |
2 | AC voltage | 200mV - 750V | 1mV - 1V | ±(0.8%+5d) - ±(1.2%+3d) |
3 | DC current | 20uA - 10A | 10nA -10mA | ±(0.8%+5d) - ±(2.0%+5d) |
4 | AC current | 2mA - 10A | 1uA -10mA | ±(1.2%+3d) - ±(3.0%+7d) |
5 | Resistance | 200 ohm - 200M ohm | 0.1 ohm - 100K ohm | ±(0.8%+5d) - ±(5.0%+10)-10d |
6 | Capacitance | 2nF - 200uF | 1pF - 100nF | ±(3%+5d) - ±(5.0%+5d) |
7 | Frequency | 2K Hz - 20K Hz | 1 Hz - 10 Hz | ±(1.5%+5) |
